电容品牌： BIGCAP®
引出方式：导针引出
标称容量： 0.1F~360F
额定电压： 2.7V/3V
计量单位： 只
外型结构： 圆柱
耐温性能： －40℃~＋70℃ 、－40℃~＋65℃
导针型超级电容器示意图：
|
型号 Part Number |
额定电压 Nominal Voltage,V |
容量 Capacitance ,F |
容量允许偏差 Cap.Tolerance |
最大内阻 ESR(Max), mΩ |
尺寸 Size, mm |
||||
|
AC@1kHz |
DC |
ΦD × L ± 1.0 |
Φd ±0.1 |
F ±0.5 |
L1 ±2.0 |
||||
|
BRP002R7L104FB |
2.7 |
0.1 |
0~+80% |
450 |
675 |
5×9.8 |
0.5 |
2 |
28 |
|
BRP002R7L224FB |
2.7 |
0.22 |
±20% |
500 |
750 |
5×9.8 |
0.5 |
2 |
28 |
|
BRP002R7L504FB |
2.7 |
0.5 |
±20% |
500 |
750 |
5×12 |
0.5 |
2 |
28 |
|
BRP002R7L504FC |
2.7 |
0.5 |
±20% |
500 |
750 |
6.3×9.8 |
0.5 |
2.5 |
28 |
|
BRP002R7L504FH |
2.7 |
0.5 |
0~+40% |
500 |
750 |
6.3×912 |
0.5 |
2.5 |
28 |
|
BRP002R7L105FA |
2.7 |
1.0 |
0~+40% |
300 |
450 |
8×13 |
0.6 |
3.5 |
30 |
|
BRP002R7L105FC |
2.7 |
1.0 |
0~+80% |
200 |
300 |
8×13 |
0.6 |
3.5 |
30 |
|
BRP002R7L105FD |
2.7 |
1.0 |
±20% |
300 |
450 |
6.3×12 |
0.5 |
2.5 |
28 |
|
BRP002R7L335FA |
2.7 |
3.3 |
-10%-+30% |
80 |
120 |
10×20 |
0.6 |
5 |
30 |
|
BRP002R7L335FB |
2.7 |
3.3 |
±20% |
100 |
150 |
10×16 |
0.6 |
5 |
30 |
|
BRP002R7L505FA |
2.7 |
5.0 |
±20% |
70 |
105 |
10×20 |
0.6 |
5 |
30 |
|
BRP002R7L106FA |
2.7 |
10 |
±20% |
50 |
75 |
12.5×26 |
0.6 |
5 |
30 |
|
BRP002R7L106FD |
2.7 |
10 |
-10%-+30% |
50 |
75 |
10×30 |
0.7 |
5 |
30 |
|
BRP002R7L506FA |
2.7 |
50 |
±20% |
20 |
30 |
18×41 |
0.8 |
7.5 |
28 |
|
BRP002R7L606FA |
2.7 |
60 |
±20% |
15 |
22.5 |
18×41 |
0.8 |
7.5 |
28 |
|
BRP003R0L104FB |
3.0 |
0.1 |
0~+80% |
450 |
675 |
5×9.8 |
0.5 |
2 |
28 |
|
BRP003R0L224FB |
3.0 |
0.22 |
±20% |
500 |
750 |
5×9.8 |
0.5 |
2 |
28 |
|
BRP003R0L504FB |
3.0 |
0.5 |
±20% |
500 |
750 |
5×12 |
0.5 |
2 |
28 |
|
BRP003R0L504FC |
3.0 |
0.5 |
±20% |
500 |
750 |
6.3×9.8 |
0.5 |
2.5 |
28 |
|
BRP003R0L504FH |
3.0 |
0.5 |
0~+40% |
500 |
750 |
6.3×912 |
0.5 |
2.5 |
28 |
|
BRP003R0L105FA |
3.0 |
1.0 |
0~+40% |
300 |
450 |
8×13 |
0.6 |
3.5 |
30 |
|
BRP003R0L105FC |
3.0 |
1.0 |
0~+80% |
200 |
300 |
8×13 |
0.6 |
3.5 |
30 |
|
BRP003R0L105FD |
3.0 |
1.0 |
±20% |
300 |
450 |
6.3×12 |
0.5 |
2.5 |
28 |
|
BRP003R0L505FA |
3.0 |
5.0 |
±20% |
70 |
105 |
10×20 |
0.6 |
5 |
30 |
|
BRP003R0L106FA |
3.0 |
10 |
±20% |
50 |
75 |
12.5×26 |
0.6 |
5 |
30 |
|
BRP003R0L106FD |
3.0 |
10 |
-10%-+30% |
50 |
75 |
10×30 |
0.7 |
5 |
30 |
|
BRP003R0L506FA |
3.0 |
50 |
±20% |
20 |
30 |
18×41 |
0.8 |
7.5 |
28 |
|
BRP003R0L606FA |
3.0 |
60 |
±20% |
15 |
22.5 |
18×41 |
0.8 |
7.5 |
28 |
盖板型超级电容器示意图：
|
型号 Part Number |
额定电压 Nominal Voltage,V |
容量 Capacitance, F |
容量允许偏差 Cap.Tolerance |
最大内阻 ESR(Max), mΩ |
尺寸 Size, mm |
|||
|
AC@1kHz |
DC |
ΦD × L ± 1.0 |
F ±0.5 |
L1 ±2.0 |
||||
|
BRP002R7S107FA |
2.7 |
100 |
±20% |
12 |
18 |
22.4×45.5 |
10 |
5.5 |
1.圆柱外形结构，超低内阻;符合ROHS标准，无Cd、Pb等污染物质;
2.充放电循环寿命长;
3.适合中大功率放电;耐压高，达到3.0V，同等条件下使用高可靠性。
1.工作电流100mA~几百A，工作时间微秒级至几分钟;
2.可用于启动装置、雷管、税控机，玩具，电力设备等。
