Brand：BIGCAP@
Terminal：
Nominal capacity：0.047~5.0F
Nominal voltage：5.5V~7.5V
Unit of measurement：PC
Structure：Cylinder
Temperature feature: －40C~+85C
两端引出式产品外形示意图：
| Part Number | Nominal Voltage ,V dc |
Capacitance F |
Cap.olerance | ESR，mΩ | Size，mm | ||||
| AC@1kHz | DC | ΦD×L | φd | F | L1 | ||||
| BMT005R5L473FA | 5.5 | 0.047 | 0~+80% | 900 | 1350 | 11×6×13 | 0.5 | 7 | 27 |
| BMT005R5L473FB | 5.5 | 0.047 | 0~+80% | 900 | 1350 | 11×6×12 | 0.5 | 7 | 27 |
| BMT005R5L104FA | 5.5 | 0.1 | ±20% | 1000 | 1500 | 11×6×13 | 0.5 | 7 | 27 |
| BMT005R5L104FB | 5.5 | 0.1 | ±20% | 1000 | 1500 | 13×7×14 | 0.5 | 9 | 27 |
| BMT005R5L224FA | 5.5 | 0.22 | 0~+40% | 800 | 1200 | 13×7×14 | 0.5 | 9 | 27 |
| BMT005R5L224FB | 5.5 | 0.22 | ±20% | 800 | 1200 | 11×6×13 | 0.5 | 7 | 27 |
| BMT005R5L224FC | 5.5 | 0.22 | ±20% | 1000 | 1500 | 13×7×12 | 0.5 | 9 | 27 |
| BMT005R5L334FA | 5.5 | 0.33 | 0~+40% | 800 | 1200 | 17×9×15 | 0.6 | 12 | 29 |
| BMT005R5L474FA | 5.5 | 0.47 | 0~+40% | 600 | 900 | 17×9×15 | 0.6 | 12 | 29 |
| BMT005R5L474FB | 5.5 | 0.47 | 0~+80% | 400 | 600 | 17×9×21 | 0.6 | 12 | 29 |
| BMT005R5L474FC | 5.5 | 0.47 | 0~+80% | 400 | 600 | 17×9×15 | 0.6 | 12 | 29 |
| BMT005R5L474FD | 5.5 | 0.47 | ±20% | 600 | 900 | 13×7×14 | 0.5 | 12 | 27 |
| BMT005R5L105FA | 5.5 | 1 | ±20% | 280 | 420 | 17×9×21 | 0.6 | 12 | 29 |
| BMT005R5L105FB | 5.5 | 1 | ±20% | 280 | 420 | 21×10×21 | 0.6 | 15 | 29 |
| BMT005R5L105FO | 5.5 | 1 | ±20% | 600 | 900 | 17×9×15 | 0.6 | 12 | 29 |
| BMT005R5L155FA | 5.5 | 1.5 | ±20% | 200 | 300 | 17×9×21 | 0.6 | 12 | 29 |
| BMT005R5L155FB | 5.5 | 1.5 | ±20% | 240 | 360 | 17×9×18 | 0.6 | 12 | 29 |
| BMT005R5L155FH | 5.5 | 1.5 | 0~+40% | 160 | 240 | 21×10×21 | 0.6 | 15 | 29 |
| BMT005R5L155FJ | 5.5 | 1.5 | ±20% | 160 | 240 | 21×10×18 | 0.6 | 15 | 29 |
| BMT005R5L205FA | 5.5 | 2 | 0~+40% | 140 | 210 | 26×13×22 | 0.6 | 18 | 27 |
| BMT005R5L205FC | 5.5 | 2 | ±20% | 120 | 180 | 21×10×21 | 0.6 | 15 | 29 |
| BMT005R5L205FO | 5.5 | 2 | 0~+40% | 180 | 270 | 17×9×21 | 0.6 | 12 | 29 |
| BMT005R5L255FA | 5.5 | 2.5 | ±20% | 140 | 210 | 21×10×21 | 0.6 | 15 | 29 |
| BMT005R5L305FA | 5.5 | 3 | ±20% | 140 | 210 | 21×10×21 | 0.6 | 15 | 29 |
| BMT005R5L355FO | 5.5 | 3.5 | ±20% | 130 | 195 | 21×10×21 | 0.6 | 15 | 29 |
| BMT005R5L405FA | 5.5 | 4 | ±20% | 100 | 150 | 26×13×22 | 0.6 | 18 | 27 |
| BMT005R5L405FC | 5.5 | 4 | ±20% | 100 | 150 | 26×13×21 | 0.6 | 18 | 27 |
| BMT005R5L405FO | 5.5 | 4 | ±20% | 90 | 135 | 17×9×34 | 0.6 | 12 | 29 |
| BMT005R5L405FQ | 5.5 | 4 | ±20% | 110 | 165 | 21×10×21 | 0.6 | 15 | 29 |
| BMT005R5L505FA | 5.5 | 5 | ±20% | 100 | 150 | 26×13×27 | 0.6 | 18 | 27 |
| BMT005R5L505FO | 5.5 | 5 | ±20% | 130 | 195 | 21×10×26 | 0.6 | 15 | 29 |
| BMT005R5L605FO | 5.5 | 6 | ±20% | 120 | 180 | 21×10×29 | 0.6 | 15 | 29 |
| BMT005R5L765FO | 5.5 | 7.6 | 0~+40% | 120 | 180 | 49×17×28 | 0.8 | 25.5 | 29 |
| BMT005R5L805FA | 5.5 | 8 | ±20% | 90 | 135 | 26×13×27 | 0.6 | 18 | 27 |
| BMT005R5L805FB | 5.5 | 8 | ±20% | 60 | 90 | 33×17×23 | 0.8 | 24 | 29 |
| BMT005R5L805FC | 5.5 | 8 | ±20% | 60 | 90 | 33×17×28 | 0.8 | 24 | 29 |
| BMT005R5L106FA | 5.5 | 10 | ±20% | 50 | 75 | 33×17×28 | 0.8 | 24 | 29 |
| BMT005R5L106FO | 5.5 | 10 | ±20% | 60 | 90 | 26×13×35 | 0.6 | 18 | 27 |
| BMT005R5L126FO | 5.5 | 12 | 0~+40% | 80 | 120 | 33×17×28 | 0.8 | 24 | 29 |
| BMT005R5L156FA | 5.5 | 15 | ±20% | 50 | 75 | 33×17×35 | 0.8 | 24 | 29 |
| BMT005R5L256FA | 5.5 | 25 | ±20% | 40 | 60 | 37×19×43 | 0.8 | 26 | 29 |
| BMT005R5L306FA | 5.5 | 30 | ±20% | 30 | 45 | 37×19×43 | 0.8 | 26 | 29 |
| BMT007R5L104FA | 7.5 | 0.1 | 0~+80% | 1200 | 1800 | 19.5×7×14 | 0.5 | 10 | 27 |
| BMT007R5L334FA | 7.5 | 0.33 | 0~+80% | 600 | 900 | 25×9×15 | 0.6 | 13.5 | 29 |
| BMT007R5L704FA | 7.5 | 0.7 | ±20% | 420 | 630 | 25×9×21 | 0.6 | 13.5 | 29 |
| BMT007R5L105FA | 7.5 | 1 | ±20% | 300 | 450 | 25×9×21 | 0.6 | 13.5 | 29 |
| BMT007R5L105FB | 7.5 | 1 | ±20% | 240 | 360 | 31×11×18 | 0.6 | 16 | 29 |
| BMT007R5L155FA | 7.5 | 1.5 | 0~+40% | 210 | 315 | 39×13×22 | 0.6 | 21 | 29 |
| BMT007R5L155FB | 7.5 | 1.5 | 0~+40% | 210 | 315 | 31×10×21 | 0.6 | 16 | 29 |
| BMT007R5L205FA | 7.5 | 2 | ±20% | 210 | 315 | 31×10×21 | 0.6 | 16 | 29 |
| BMT007R5L255FA | 7.5 | 2.5 | ±20% | 150 | 225 | 39×13×22 | 0.6 | 21 | 27 |
| BMT007R5L335FA | 7.5 | 3.3 | ±20% | 150 | 225 | 39×13×27 | 0.6 | 21 | 29 |
| BMT007R5L505FA | 7.5 | 5 | ±20% | 90 | 135 | 49×17×28 | 0.8 | 25.5 | 29 |
中间引出式产品外形示意图：
| Part Number | Nominal Voltage ,V dc |
Capacitance F |
Cap.olerance | ESR，mΩ | Size，mm | ||||
| AC@1kHz | DC | ΦD×L | φd | F | L1 | ||||
| BMT005R5L474FG | 5.5 | 0.47 | 0~+80% | 180 | 270 | 21×10×21 | 0.6 | 5.3 | 29 |
| BMT005R5L474FH | 5.5 | 0.47 | 0~+40% | 600 | 900 | 17×9×15 | 0.6 | 5 | 29 |
| BMT005R5L474FJ | 5.5 | 0.47 | 0~+80% | 400 | 600 | 17×9×15 | 0.6 | 5 | 29 |
| BMT005R5L105FD | 5.5 | 1 | ±20% | 280 | 420 | 17×9×21 | 0.6 | 5 | 29 |
| BMT005R5L155FC | 5.5 | 1.5 | ±20% | 200 | 300 | 17×9×21 | 0.6 | 5 | 29 |
| BMT005R5L205FB | 5.5 | 2 | 0~+40% | 140 | 210 | 26×13×22 | 0.6 | 7.5 | 27 |
| BMT005R5L205FP | 5.5 | 2 | ±20% | 180 | 270 | 17×9×21 | 0.6 | 5 | 29 |
| BMT005R5L305FB | 5.5 | 3 | ±20% | 140 | 210 | 21×10×21 | 0.6 | 5.3 | 29 |
| BMT005R5L505FP | 5.5 | 5 | ±20% | 130 | 195 | 21×10×26 | 0.6 | 5.3 | 29 |
1.Cylindrical structure, ultra-low internal resistance;
2.Comply with ROHS standards, no Cd, Pb and other pollutants
3.Long charging and discharging cycle life
4.Suitable for medium and high power discharge;
Working current 100mA~ hundreds of A, working time from microsecond to several minutes; Can be used for starting devices, detonators, tax control machines, toys, electrical equipment, etc
Products are tested under normal pressure, the temperature range is 5-35 ℃ and relative humidity is less than RH85% .The standard test conditions in this product specification are as follows: under normal pressure; the temperature at 25 ℃ and the relative humidity less than 60%
