Brand： BIGCAP@
Terminal：
Nominal capacitance ：0.1F~20F
Nominal volrage：2.7V
Unit of measurement：pc
Structure: Cylinder
Temperature performance：-40C~+85C
导针型超级电容器示意图：
| Part Number | Nominal Voltage ,V dc |
Capacitance F |
Cap.olerance | ESR，mΩ | Size，mm | ||||
| AC@1kHz | DC | ΦD×L | Φd | F | L1 | ||||
| BRT002R7L104FA | 2.7 | 0.1 | 0~+40% | 450 | 675 | 5×12 | 0.5 | 2 | 28 |
| BRT002R7L154FA | 2.7 | 0.15 | ±20% | 400 | 600 | 5×12 | 0.5 | 2 | 28 |
| BRT002R7L224FA | 2.7 | 0.22 | ±20% | 500 | 750 | 5×12 | 0.5 | 2 | 28 |
| BRT002R7L254FA | 2.7 | 0.25 | ±20% | 500 | 750 | 5×12 | 0.5 | 2 | 28 |
| BRT002R7L354FA | 2.7 | 0.35 | ±20% | 400 | 600 | 5×12 | 0.5 | 2 | 28 |
| BRT002R7L504FA | 2.7 | 0.5 | 0~+40% | 500 | 750 | 6.3×12 | 0.5 | 2.5 | 28 |
| BRT002R7L105FA | 2.7 | 1 | 0~+40% | 300 | 450 | 8×13 | 0.6 | 3.5 | 30 |
| BRT002R7L205FA | 2.7 | 2 | ±20% | 140 | 210 | 8×19 | 0.6 | 3.5 | 30 |
| BRT002R7L205FB | 2.7 | 2 | ±20% | 140 | 210 | 10×20 | 0.6 | 5 | 30 |
| BRT002R7L305FA | 2.7 | 3 | 0~+40% | 100 | 150 | 8×19 | 0.6 | 3.5 | 30 |
| BRT002R7L405FA | 2.7 | 4 | ±20% | 80 | 120 | 10×20 | 0.6 | 5 | 30 |
| BRT002R7L505FA | 2.7 | 5 | ±20% | 70 | 105 | 10×20 | 0.6 | 5 | 30 |
| BRT002R7L605FA | 2.7 | 6 | ±20% | 70 | 105 | 10×20 | 0.6 | 5 | 30 |
| BRT002R7L705FA | 2.7 | 7 | ±20% | 70 | 105 | 10×25 | 0.6 | 5 | 30 |
| BRT002R7L805FA | 2.7 | 8 | ±20% | 50 | 75 | 12.5×21 | 0.5 | 5 | 28 |
| BRT002R7L106FA | 2.7 | 10 | ±20% | 50 | 75 | 12.5×26 | 0.5 | 5 | 30 |
| BRT002R7L126FB | 2.7 | 12 | 0~+40% | 50 | 75 | 12.5×26 | 0.5 | 5 | 30 |
| BRT002R7L156FA | 2.7 | 15 | ±20% | 30 | 45 | 16×26 | 0.8 | 7.5 | 30 |
| BRT002R7L166FA | 2.7 | 16 | ±20% | 30 | 45 | 16×21 | 0.8 | 7.5 | 30 |
| BRT002R7L206FA | 2.7 | 20 | ±20% | 25 | 37.5 | 16×34 | 0.8 | 7.5 | 30 |
1. Cylindrical shape, ultra-low internal resistance;
2.Comply with ROHS standards, no Cd, Pb and other pollutants;
3.Long charge and discharge cycle life;
4. Suitable for medium and high power discharge
5.gh temperature resistant, can be used in + 85 ℃ environment.
working current from100mA to several hundred A, working time from microsecond to several minutes；
Can be used for starting devices, detonators, tax control machines, toys, power equipment, etc.
Products are tested at the condition of standard atmospheric pressure, temperature 5 ~ 35 ℃, relative humidity is less than 85%. The standard test condition is this specification is standard atmospheric pressure, temperature of 25 ℃, relative humidity is less than 60%
